Weller Tools GmbH

WR 3000M

Downloads

WR 3000M

Item No.: T0053368399N
3-Channel Rework Station Set, 360 W (400 W) for vertical applications
Product features
  • Power unit WR 3M, 3 channels with soldering iron WP 80, desoldering iron DXV 80 and hot air iron HAP 200

  • Large all round set for all repair jobs

  • Desoldering iron DXV 80 for vertical applications

  • Simultaneous operation of hot air and desoldering

Downloads
Technical data
Width 240.0 mm
Height 103.0 mm
Length 280.0 mm
Dimensions L x W x H 280.0 x 240.0 x 103.0mm
Capacity (l/min) 18 l/min
Desoldering Yes
Equipotential Bonding Socket Via 3.5mm Pawl Socket on Back of Device (Hard-Grounded)
ESD Safe Yes
Hot Air (picto) Yes
IPC Compliant (Tip to Ground) Corresponds to IPC-J-001
Maximum Hot Air Flow Rate l/min (Depends on Tool) 15 l/min
Maximum Volume 0.7 bar
Number of Channels 3
Power 360 W (400 W)
Temperature Accuracy °C ± 9 °C
Temperature Accuracy °F ±17 °F
Temperature Range °C 50 - 550 °C
Temperature Range °F 150 - 950 °F
Temperature Stability °C ±2 °C
Temperature Stability °F ±4 °F
Tip Type WT
UPC 4003019417643
USB Yes
Voltage 230 V

Accessory

Irons/Tweezers

Items in the Box
