FT 12
Item No.:
112-0000-ESDN
Fume extraction unit
Product features
-
Up to 2 FE soldering irons can be connected
-
Maintenance-free compressed air converter
-
Portable unit for stand alone applications for industrial long term use
-
For industrial long term use
-
A compressed air cleaning filter removes additional odors caused by the compressed air.
-
Maintenance-free compressed air converter
Downloads
pdf
pdf
(8.32 MB)
Technical data
| Height | 200mm |
| Length | 120mm |
| Dimensions L x W x H | 120.0 x 120.0 x 200.0mm |
| Air Consumption | 27 l/min |
| Compact Filter | Particle filter H13, broadband gas filter (50% activated carbon + 50% Chemisorb) |
| ESD Safe | Yes |
| Maximum Blower Vacuum (Pa) | 20,000 Pa |
| Maximum Capacity | 1–2 Workstations |
| Power | 6 Bar |
| UPC | 037103310514 |
| Weight (Catalog) | 1.70 kg |
| Product Family | Solder Fumes Direct Extraction 1-2 Workstations |
